What is an electrical substation container?

Le Converted shipping container An electrical substation is a turnkey solution for housing electrical equipment, ensuring the protection of installations in a secure environment adapted to technical requirements. Ideal for industrial sectors, construction sites, or energy infrastructure, it will be configured according to your specifications or specific needs.

Everything you need to know about the development of electrical substation container

Application areas

The containers offer great versatility of use and can be used in particular for:

local HT-BT

transformer room

local battery storage

local inverter

fuel cell facility for the hydrogen sector

Delivery station

Specifications

Robustness and Durability

Made from high-strength steel, reinforced to withstand extreme weather conditions
Anti-corrosion exterior coating suitable for humid and saline environments
Structural resistance suitable for the integration of heavy equipment such as transformers or TGBT

Adaptation for integration of your process

Wall or ceiling supports allowing you to mount your equipment (internal/external)
Fixing points flush with the interior floor, taken up on the structure on the underside, when fixing directly to the floor
Supports for cable trays or rails 41*41 / 41*21
Roof reinforcement crosspieces for installing equipment on the roof
Cable passage allowing the installation of:
- stuffing box
- waterproof case type ROXTEC or equivalent
- socket of any type

Cable hatches
Adaptation of single or double leaf doors (with or without insulation, acoustics, fire protection, etc.). Custom dimensions allowing easy access for the integration of equipment.
Possibility to modify or integrate:
- a type of lock to comply with access constraints for electrical premises or secure premises
- a type of seal depending on your operating site constraints or the degree of internal sealing
- A glazing

Thermal, acoustic or fire insulation

Thermal insulation to ensure optimum temperature for your electrical equipment
Sound insulation in case of noise requirements to be met
Fireproof insulation to meet a specific fire resistance constraint linked to the protection of the production site

Technical false floor

Integration on request of a technical false floor in 600*600 mm slabs in chipboard panels set in a steel sheet tray covered with laminate, the whole is placed on jacks at the requested height
Specific manufacture of false flooring in metal or resin grating, allowing air circulation
Manufacture of custom-made metal frames with fixing holes adapted to your equipment, to raise cabinets to the height of the false floor

Flooring

Covering the original wooden floor with a floor:
- in painted steel sheet
- in stainless steel sheet
- in aluminum sheet
- with a smooth / checkered / checkered texture
- - Sheet metal floors can be glued, screwed or welded continuously in case of retention
Covering the wooden floor with a smooth resin coating or made non-slip by spraying sand
Covering the wooden floor with linoleum or tile flooring

The choice of an electric container, specifically designed according to the integration constraints and the production site, offers numerous practical and operational advantages:

Mobility and multimodal transport capacity

- The containers are easily transportable and lightweight compared to a concrete post, which does not require handling equipment or a specific convoy for delivery.
- Thanks to CSC approval after structural modification, a new certification guarantees worldwide delivery, in accordance with ISO standards.
Economy and Profitability

- The electric container offers a long-term economical solution thanks to its durability and low maintenance costs.
Adaptable and Customizable Solution

- The modularity of the electrical substations allows for the rapid creation of installations adapted to the precise needs of each piece of equipment: TGBT, transformer substation, delivery substation, battery room, inverter room

Transport with or without unloading to your site as an option.

TGBT container

Local electrical container compatible with CSC

Container load bank

Electrical cabinet container

Container transformer

Design office:
7 projectors accompany you for the success of your projects

Creation of 3D plans in Inventor
Integration of your equipment
Creation of support plans and customer interfaces
Structural calculation notes
Sizing for CSC maritime approval
